| List Price | : | $15,680.00 | |
|---|---|---|---|
| Our Price | : | Request Quote | |
| SKU | : | RAW-GTX20GN20K | |
| Availability | : |
Email or call 208-265-0415 to confirm. |
|
RawMaxx Trailers are built to a higher standard than any other trailer in their price range.
Take a look at the competition and then come buy a better trailer for less money from RawMaxx.
You will not be disappointed!
Please Note: Many other trailer sizes, styles, load ratings and configurations are availble. Let us know what you need and we will be happy to help!
| SKU | RAW-GTX20GN20K |
|---|---|
| Model | GTX20GN20K |
| Length, Deck | 20' |
| Width, Deck | 102" |
| Height, Deck | 24" |
| Weight | 4000 lbs |
| Weight Rating | GVWR: 14,000 lbs. GAWR: 7,000 lbs. |
| Finish | Powder Coat |
| Hitch Connection Type | 2-5/16" Adjustable Ball Coupler |
| Jack(s) | Front Jacks: 2 Side Wind Drop Legs - 10,000 lbs. |
| Tool Box | Front Tool Box: Between Risers / Lockable Latch |
| Gooseneck | Winch Plate: Winch Ready Chain Rack & Tray Chain Rack: For 12 Chains Gooseneck Neck Length: 96" |
| Safety System | Safety Chains: 3/8" G70 Safety Chains Breakaway System: Electric Breakaway Kit Reflective Tape: 3M DOT Compliant Reflective Tape |
| Frame / Deck | Side Side Perimeter: 3/16" Formed Thread Plate Stake Pockets: 3-5/8" x 1-1/2" (ID) Stake Pockets Rub Rail: 2" Rub Rail With Spools Fenders: 3/16" Treadplate ( Drive-Over ) Fenders Frame Frame: 8" x 13 lb. I-beam Frame Cross-Members: 3" Channel / 16" Spacings Gravity Tilt Deck Front Deck: 4' Stationary Deck Deck: 16' Tilt Deck Tilt System: Gravity Up / Down Tilt Angle: 11° Flooring: 2” Treated Lumber Deck D-Rings: 4 D-Rings (Welded Inside Fenders) X-Track Ready: Snap D-Rings (Sold Separately) |
| Color | Black (Other Colors Available/Optional) |
| Running Gear | Tires Type: Radial Tires Size: ST235/80R16 Ply: 10 Ply Rating: 3,520 lbs. Rims: 16” Black Mod Wheels Bolt Pattern: 8 on 6.5” Suspension Axle Type: Torsion Axles: 2 Rating: 7,000 lbs. Brakes: Electric Type: Torflex |
| Electrical & Lighting | Wiring Front Plug: 7 - Way RV Frame Wiring: All Weather Wiring Harness Lighting Side Markers: 3/4" LED Bullet Lights Rear Lights: DOT Approved LED Lights |
| Warranty, Axles | 5 Year Dexter |
| Manufacturer's Warranty | 3 Year Structural / 1 Year Paint |
| Country of Manufacture | Mexico |
