Befco's Till-Rite tillers offer a complete range of side-shift, sturdy, versatile and economical rotary tillers. Five different models are available: T30, T40, T50, T60 and T70 for tractors ranging from 16 to 70 HP at 540 rpm.
These machines can be used anywhere from orchards to nurseries, from vineyards to green houses and in all types of landscaping jobs. Working widths vary from 42" to 82".
The built in smooth manual side-shift system which requires no lever to operate allows the machines to work totally shifted to the right, therefore closer to plants, sidewalks flower beds, etc., as well as in central position just like any normal centered tiller covering both tractor tire tracks.
Features:
â–ª Highly engineered & rugged gearbox with cooling fins.
â–ª Smooth manual side-shift system.
â–ª Adjustable side skids for working depth control.
â–ª Heavy duty shielded PTO shaft with shear pin coupling (1 3/8" ASAE cat. 2) or slip clutch safety (1 3/8" ASAE cat. 3).
â–ª Max. working depth 7 1/4".
â–ª Parking stand.
â–ª Reinforced lateral #60 chain drive transmission in oil bath.
â–ª Four blades per flange.
â–ª High carbon solid steel round rotor shaft allows for a deeper working depth.
â–ª Outward turned blades keep the rotor supports clean and maximize working width.
â–ª Heavy duty full size blades.
â–ª 3 point linkage, cat. 1.
â–ª Some assembly required.
More Information
SKU
BEF-T30-150
Weight
374 lbs
Identifier
BEF-7135
Model
T30-150 / T30-250 / T30-550
Horsepower Recommended
25 - 30 HP (18.6 - 22.4 KW)
Width - Overall
58" (147 cm)
Width - Working
50" (127 cm)
Side Shift
10" (25 cm)
Tines / Rods
20 Total - 4 Blades per Flange; 5 Flanges
Tilling Depth
Up to 7-1/4" (18 cm)
Unit Drive Type
540 RPM Rear Tractor PTO (2,000 RPM Optional)
PTO Shaft
Included, with Shear-Bolt Protection (Slip Clutch Optional)
